Drill Steel Pipe For Mineral Mining , Alloy Steel Grade Oil Drill Pipe

  • 1
  • 2
  • 3

Brand Name : TORICH

Model Number : DCDMA (USA), BS4019 (UK), METRIC (SWEDEN)

Certification : ISO9001:2008, ISO14001:2008, TS16949

Place of Origin : China

MOQ : 5 TONS

Price : 1500-3000 USD/ton

Supply Ability : 10000 tons per year

Delivery Time : 5-8 weeks

Packaging Details : In hexagonal bundles

Material : Alloy Steel Grade

Type : DCDMA (USA), BS4019 (UK), METRIC (SWEDEN)

Production : Cold Drawn

Heat Treatment : +N, Q+T

Application : Wire Line,Drill Rod, Core Barrel

Standard : GB/T9808-2008

Contact Now

Drill Pipes for Oil and Mineral Mining





Applications: For Geological Drill underground for Oil and Mineral, for Mining Exploration
Straightness, Concentricity, Mechanical Properties can meet the requirement of DCDMA (USA), BS4019 (UK), METRIC (SWEDEN)
Size range: O.D.:6-95mm     W.T.:1-10mm      L:max12000mm


Standard Producton Method Tube Size   Tolerance
GB/T 9808-2008 Hot rolled OD (+1.0%D) +0.65
(-0.5%D) -0.35
WT ≤10 (+15%S)  +0.45
 (-10%S)  -0.35
＞10 (+12.5%S, -10%S)
Cold Drawn OD   ±0.50%D or ±0.20
WT   ±8%S or ±0.15
Q(N)/ T118-2010 Cold Drawn OD OD ±0.40%D or ±0.20
WT WT ±7%S or ±0.15



Normal Sizes:

Designation Outside Diameter (mm) Inside Diameter (mm)
  Min Max Min Max
A Wireline 44.45  44.70  34.82  35.07
B Wireline 55.55  55.90  45.95  46.30
N Wireline 69.95  70.30  60.05  60.30
H Wireline 88.90  89.38  77.62  78.10
P Wireline 114.30  114.78  102.79  103.27



Mechanical Properties:


Stee Grade Tensile Strength
Mpa min		 Yield Strength
Mpa min		 Elongation
%  min		 HRC Heat Treatment
      T600 790 600 14 ~ N
      T750 850 750 14 26-31 QT
      T850 950 850 14 28-33 QT



Chemical composition


Stee Grade C Si Mn P max S max Cu max Cr Mo B
     T600
(45MnMoB)		 0.43-0.48 0.17-0.37 1.05-1.35 0.02 0.015 0.20  ~ 0.20-0.25 0.001-
0.005
      T750
(30CrMnSiA)		 0.28-0.34 0.90-1.20 0.80-1.10 0.02 0.015 0.20  0.8-1.1 ~ ~
    T850
    4140		 0.38-0.43 0.17-0.35 0.70-0.90 0.02 0.015 0.20  0.9-1.1 0.15-
0.25		 ~



Mechanical Properties:


Steel  Tensile Strength Mpa Yield Point Mpa Elongation % Heat treatment
Grade min
ZT380 640 380 14 Normlized
ZT490 690  490  12  Normlized
ZT540 740  590  12  Normlized
ZT590 770  590  12  Normlized
ZT640 790  640  12  QT
ZT740 840  740  10  QT
T850 950  850  15  QT



Drill Steel Pipe For Mineral Mining , Alloy Steel Grade Oil Drill Pipe Drill Steel Pipe For Mineral Mining , Alloy Steel Grade Oil Drill Pipe
